NATURAL STONE
Presentable appearance, durability, environmental friendliness and weather resistance are the features of such facing material as natural stone are the features of such facing material as natural stone.
Such rocks as marble, limestone and natural granite are used for production of facing plates made of natural stone.
Marble has high strength and wear-resisting characteristics; however, it is easily processed and takes mirror grinding. This material has its own inimitable pattern in a form of veinlets and unusual structure.
Limestone is a porous natural material; it is easily worked, cut and grinded. Facing plate made of such material can “breathe” thanks to its porous structure and keeps water out as well.
Invisible Hangers
MVe-Light V08
EnVe-Light V08
This aluminum system is designed for vertical substructures in ventilated facades and includes wall brackets, profiles, and accessories. Bracket extenders allow for different cladding offsets. Wall brackets are available in 45–305 mm (with isolator) and 40–300 mm (without isolator), in 10–30 mm increments, and three sizes (S, M, L). They feature various hole geometries to suit installation with anchors or screws.
Preassembled isolators on the brackets reduce thermal bridging by separating the substructure from the base wall, improving overall energy efficiency. Each bracket has two fixing points—fixed and sliding. The fixed point carries façade and window loads, while the sliding point compensates for profile expansion. Clear markings help prevent installation errors.
Vertical profiles are attached to brackets using special screws or rivets. Fixed points secure the profiles, while sliding points allow movement without extra stress. Fastening clips aid alignment and reduce installation time.
Cladding panels are mounted using agraffe profiles and hangers. Horizontal agraffe profiles connect to vertical profiles at fixed and sliding points. Panels are hung using fixed, adjustable, or sliding hangers, which allow for alignment and secure attachment to the substructure.
Invisible Stone Profile
MVe-Light V10
EnVe-Light V10
cladding. It includes wall brackets, profiles, and accessories, along with extenders that allow various cladding offsets. Wall brackets range from 45–305 mm (with isolator) and 40–300 mm (without isolator) in 10–30 mm increments and three sizes (S, M, L). They feature different hole geometries for anchor or screw installation.
Brackets with preassembled isolators reduce thermal bridging by separating the substructure from the wall, improving the building’s thermal performance. Each bracket has fixed and sliding points—fixed points carry façade and window loads, while sliding points compensate for thermal expansion. Clear markings help prevent installation errors.
Vertical profiles are connected with specially designed screws or rivets. Fixed points hold the profile in place, while sliding points allow for movement. A fastening clip simplifies alignment and speeds up installation.
The V10 system offers hidden fixation of stone panels using horizontal profiles attached to vertical profiles with screws or rivets. Grooves cut into the panel edges allow them to slot securely onto the profiles, ensuring a stable and durable installation.
